Gel Case IPX8 - Small Size, Pack of 4

Pack of 4 gel insulation cases offering IPX8 waterproofing (permanent immersion up to 1 m). A compact solution ideal for securing small wire junctions in wet, buried, or submerged environments, without the need for soldering or poured resin.

Technical Specifications

• IPX8 rating (permanent immersion up to 1 m)
• Dimensions 4.5 x 2.8 x 1.9 cm
• Case material Polyamide (PA)
• Orange color
• Wire section up to 4 mm²
• Voltage up to 1 kV
• Ambient temperature -40°C to +50°C
• Operating temperature 90°C
• Standard EN 50393
• Halogen-free - Reusable (gel shape memory)
• Flammability UL94 HB
• Quantity per blister 4 pieces

Features

• Compact size for small junctions (2 to 3 thin wires)
• Gel shape memory: open, modify, close without loss of waterproofing
• Orange color for quick location on site
• Suitable for light buried applications: garden lighting, LED borders, irrigation

Installation

Make the connection with a connector (wago or domino), open the mini case, place the junction inside, close by pressing until it clicks. Waterproofing is effective immediately upon closing, even under immersion.

Where to use this case?

Garden LED lighting, outdoor spot connection, LED strip extensions in wet environments, light buried applications, automatic watering systems, pool surroundings.
